An overview of ring hammer crusher:

Introduction to ring hammer crusher:

Ring hammer type crushing machine and hammer type and reaction type crusher has the advantages of high efficiency, energy saving, stable operation, low noise, blast volume small, are widely used in thermal power plant for pulverized coal operations.

Working principle of ring hammer crusher:

The main working parts of ring hammer crusher rotor with ring hammer. Rotor is composed of ring hammer shaft and ring hammer. The motor drives the rotor to rotate at high speed in the crushing cavity. The broken material from the upper to the feed port into the machine, by the high-speed rotation of the hammer blow, and the material interaction between the collision, extrusion, grinding effect and broken. Below the rotor portion, a grate plate, broken less than grate hole size granularity level through the grate plate exclusion, greater than size of grate hole size of materials to ring hammer blow by, finally through the grate plate out of the machine.

Ring hammer type crusher main structure:

Ring hammer crusher body mainly consists of the following parts, part of the frame body, rotor, comb board, synchronized regulation device, an upper cover of the hydraulic open device and other components. The host is composed of a hydraulic coupler is connected with a motor, direct start.
